Li-ion Tamer Sensor MOS

LT-SEN-MOS

The Li-ion Tamer Sensor Multi Output Solution (MOS) is a device that detects hydrogen gas, which is generated during thermal runaway of lithium-ion batteries. The detection of hydrogen allows proper management of flammable gas accumulation to avoid explosive conditions. It is also capable of detecting the initial venting of battery electrolyte solvent vapours (off-gassing phase) that occurs early in the failure mode of lithium-ion batteries. The early detection of such events allows proper mitigation steps to be taken to avoid a catastrophic thermal runaway failure.

Features & Benefits
Technical Data
Accessories
Documents

• Early warning of lithium-ion battery failures
• Enable thermal runaway prevention with proper mitigation actions
• Single cell failure detection without electrical or mechanical contact of cells
• Extended product lifetime
• Calibration-free product (only requires bump test)
• Highly reliable output signal
• Low power consumption
• Cost Effective solution for modular Battery Energy Storage Systems (BESS)
• Compatible with all lithium-ion battery form factors and chemistries
• Easy installation
• Independent and redundant perspective on battery health
• Reduction/removal of false positive signals
• Support 2 alarm relay outputs and 1 fault relay output
• Configurable communication protocols including Relay outputs and Modbus/Canbus selection communication

Dimensions [mm]	140 (L) x 85 (W) x 34 (H)
Input Power Range	15 - 32VDC Typical 24VDC
Max. Sensors per Module	1
System Outputs	3 Relay outputs/MODBUS/CANBUS
Current consumption (with Sensors)	65mA, Max 1.56W (@ 24VDC)
Relay Load	Max. 30 VDC 2A; Max. 125 VAC 0.5 A
Output	RJ45 0.25W (5VDC/ 0.5mA) power supply for sensor
Temperature	40 °C to 50 °C
Humidity	5 % to 90 %RH (non-condensing)
Max. Temperature Change	8.6 °C/min

Spare parts:
LT-SEN-IM-UL Li-ion Tamer Interface Module UL
LT-SEN-M Li-ion Tamer Gen 2+ Sensor
